• Air conditioning, dual-zone, manual, individual climate settings for driver and right front passenger (Upgradeable to (CJ2) Air conditioning, dual-zone, automatic on Extended and Crew Cab Models)
• Assist handle, front passenger (Also includes rear outboard passenger assist handle on Extended and Crew Cab Models)
• Cigarette lighter, on instrument panel
• Coat hook, driver side (Also includes passenger side coat hook on Extended and Crew Cab Models)
• Console, overhead mini, includes map lights (Not available with (CF5) Sunroof, power)
• Cruise control, electronic with set and resume speed, includes telltale in instrument panel cluster
• Cupholders, front (Also includes rear cupholders on Extended and Crew Cab Models)
• Defogger, rear-window, electric (Not available with (A28) Window, rear sliding)
• Door locks, power
• Door trim, side reflectors (Also includes lights on SLE and SLT)
• Headliner, Shale-colored cloth, with matching retainer moldings
• Keyless entry, remote, includes 2 transmitters, panic button and content theft alarm
• Lighting, dome lamp, reading, backlit instrument panel switches and door handle-activated illuminated entry
• Mirror, inside rearview, electrochromic (light-sensitive auto dimming), 8-point compass and outside temperature indicator
• Power outlets, auxiliary, covered, 2 dash-mounted, 12-volt
• Seat trim, Custom Cloth
• Seats, front 40/20/40 split-bench, 3-passenger, driver and passenger manual reclining, center fold-down armrest with storage, adjustable outboard head restraints and storage pockets on Extended and Crew Cab Models (Not available with (UC6) Sound system, ETR AM/FM stereo with 6-disc CD changer)
• Steering wheel, leather-wrapped rim, Black, includes theft-deterrent locking feature
• Theft-deterrent system, PASSlock II
• Visors, padded, Shale-colored, driver and passenger side with cloth trim, extenders, pocket on driver side and vanity mirror on passenger side
• Warning tones, headlamp on, key-in-ignition, driver and passenger buckle up reminder, turn signal on
• Windows, power, includes driver and passenger express-down

• Alternator, 145 amps
• Battery, heavy-duty, 600 cold-cranking amps, includes rundown protection and retained accessory power
• Brakes, 4-wheel antilock, front hydraulic disc and rear drum (Not standard with (NYS) 4-wheel steering)
• Exhaust, aluminized stainless-steel muffler and tailpipe
• Four wheel drive
• Frame, hydroformed
• Pickup bed, Wideside box
• Rear axle, 3.42 ratio (Standard on 4WD Models only. - Not available with (NYS) 4-wheel steering)
• Recovery hooks, front, frame-mounted
• Steering, power
• Suspension Package, Handling/Trailering, heavy-duty includes 36mm piston monotube shocks
• Suspension, front, independent (2WD Models include coil springs. - 4WD Models include torsion bars)
• Suspension, rear, semi-elliptic 2-stage multi-leaf springs (Standard with Regular and Extended Cab Models only)
• Tire carrier, outside spare, winch-type mounted under frame at rear
• Tire, spare, full-size, 17" (43.2 cm) with steel wheel located at rear underbody of vehicle
• Tires, P265/70R17 all-season, blackwall (Requires 4WD Regular or Extended Cab Models. - Not available with (Z71) Suspension Package, Off-Road)
• Tools, mechanical jack and wheel wrench located in back of cab
• Transfer case, electronic Autotrac, includes push-button controls (Requires 4WD Models)

• Air bags, frontal, driver and right front passenger, includes Passenger Sensing System (Always use safety belts and proper child restraints, even with air bags. Children are safer when properly secured in a rear seat. See the Owner's Manual for more safety information)
• Brakes, 4-wheel antilock, front hydraulic disc and rear drum (Not standard with (NYS) 4-wheel steering)
• Daytime running lamps, includes automatic exterior lamp control

PICKUP BED, WIDESIDE BOX

(STD)

LICENSE PLATE BRACKET, FRONT

(will be forced on orders with ship-to states that require a front license plate)

TRAILERING EQUIPMENT, HEAVY-DUTY

includes trailering hitch platform 7-wire harness (harness includes wires for: park lamps backup lamps right turn left turn electric brake lead battery and ground) with independent fused trailering circuits mated to a 7-way sealed connector 7-way to 4-way trailer adapter instrument panel jumper wiring harness for electric trailer brake controller and 1-way sealed connector for center high-mounted stop/brake lamp. Also includes (K47) Air cleaner high capacity and (KNP) Cooling external transmission oil cooler.

SUSPENSION PACKAGE, HANDLING/TRAILERING, HEAVY-DUTY

includes 36mm piston monotube shocks (STD)

SEAT TRIM, CUSTOM CLOTH

(STD)

CONSOLE, FLOOR

includes storage compartment and dual cupholders

SPARE TIRE LOCK

keyed cylinder lock that utilizes same key as ignition and door

TIRES, P265/70R17, ALL-SEASON BLACKWALL

(STD)

SKID PLATE PACKAGE

includes aluminum front underbody shield starting behind front bumper and running to 1st cross-member protecting front underbody oil pan differential case and transfer case frame-mounted shields

TRANSMISSION, 4-SPEED AUTOMATIC, ELECTRONICALLY CONTROLLED W/OVERDRIVE AND TOW/HAUL MODE

(STD)

GVWR, 6400 LBS. (2903 kg)

(STD)

SLE PREFERRED EQUIPMENT GROUP

includes standard equipment

ENGINE, VORTEC 5300 V8 SFI, ALUMINUM BLOCK WITH STEEL CYLINDER SLEEVES

(310 HP @ 5200 rpm 335 lb.-ft. (452.3 N-m] @ 4000 rpm)

WHEELS, 4 - 17" X 7.5" (43.2 CM X 19.1 CM) 6-LUG POLISHED CAST ALUMINUM

includes steel spare

REAR AXLE, 3.42 RATIO

(STD)

SOUND SYSTEM, ETR AM/FM STEREO WITH CD AND CASSETTE PLAYER

includes seek-and-scan digital clock auto-tone control speed-compensated volume TheftLock Radio Data System (RDS) and 4-speakers on Regular Cab Models and 6-speakers on Extended and Crew Cab Models (with bucket seats UB1 includes Bose speaker system Bose amplifier and Bose subwoofer)

LIGHT DUTY POWER PACKAGE

includes (LM7) Engine Vortec 5300 V8 SFI or (L33) Engine Vortec 5300 V8 SFI or (L59) Engine Vortec 5300 V8 SFI (G80) Differential automatic locking heavy-duty or (G86) Differential limited slip heavy-duty and (Z82) Trailering equipment heavy duty

SEATS, FRONT RECLINING BUCKETS, INBOARD ARMRESTS, DUAL ADJUSTABLE HEAD RESTRAINTS

includes (AG1) Seat adjuster power driver 6-way and storage pockets

• AIR CLEANER HIGH-CAPACITY
• PAINT TWO-TONE
• SEAT ADJUSTER POWER DRIVER 6-WAY
• PICKUP BED WIDESIDE BOX (STD)
• LICENSE PLATE BRACKET FRONT (will be forced on orders with ship-to states that require a front license plate)
• MIRRORS OUTSIDE REARVIEW POWER FOLDING POWER HEATED BLACK DRIVER SIDE ELECTROCHROMIC (LIGHT-SENSITIVE AUTO-DIMMING) TURN SIGNAL IN GLASS AND CURB-TILT
• DIFFERENTIAL AUTOMATIC LOCKING HEAVY-DUTY REAR
• TRAILERING EQUIPMENT HEAVY-DUTY includes trailering hitch platform 7-wire harness (harness includes wires for: park lamps backup lamps right turn left turn electric brake lead battery and ground) with independent fused trailering circuits mated to a 7-way sealed connector 7-way to 4-way trailer adapter instrument panel jumper wiring harness for electric trailer brake controller and 1-way sealed connector for center high-mounted stop/brake lamp. Also includes (K47) Air cleaner high capacity and (KNP) Cooling external transmission oil cooler.
• CUSTOMER DIALOGUE NETWORK
• SUSPENSION PACKAGE HANDLING/TRAILERING HEAVY-DUTY includes 36mm piston monotube shocks (STD)
• SEAT TRIM CUSTOM CLOTH (STD)
• CONSOLE FLOOR includes storage compartment and dual cupholders
• SPARE TIRE LOCK keyed cylinder lock that utilizes same key as ignition and door
• TIRES P265/70R17 ALL-SEASON BLACKWALL (STD)
• SKID PLATE PACKAGE includes aluminum front underbody shield starting behind front bumper and running to 1st cross-member protecting front underbody oil pan differential case and transfer case frame-mounted shields
• TRANSMISSION 4-SPEED AUTOMATIC ELECTRONICALLY CONTROLLED W/OVERDRIVE AND TOW/HAUL MODE (STD)
• GVWR 6400 LBS. (2903 kg) (STD)
• AIR CONDITIONING DUAL-ZONE AUTOMATIC INDIVIDUAL CLIMATE SETTINGS FOR DRIVER AND RIGHT FRONT PASSENGER
• SLE PREFERRED EQUIPMENT GROUP includes standard equipment
• ENGINE VORTEC 5300 V8 SFI ALUMINUM BLOCK WITH STEEL CYLINDER SLEEVES (310 HP @ 5200 rpm 335 lb.-ft. (452.3 N-m] @ 4000 rpm)
• COOLING EXTERNAL TRANSMISSION OIL COOLER AUXILIARY HEAVY-DUTY AIR-TO-OIL
• WHEELS 4 - 17" X 7.5" (43.2 CM X 19.1 CM) 6-LUG POLISHED CAST ALUMINUM includes steel spare
• REAR AXLE 3.42 RATIO (STD)
• SOUND SYSTEM ETR AM/FM STEREO WITH CD AND CASSETTE PLAYER includes seek-and-scan digital clock auto-tone control speed-compensated volume TheftLock Radio Data System (RDS) and 4-speakers on Regular Cab Models and 6-speakers on Extended and Crew Cab Models (with bucket seats UB1 includes Bose speaker system Bose amplifier and Bose subwoofer)
• LIGHT DUTY POWER PACKAGE includes (LM7) Engine Vortec 5300 V8 SFI or (L33) Engine Vortec 5300 V8 SFI or (L59) Engine Vortec 5300 V8 SFI (G80) Differential automatic locking heavy-duty or (G86) Differential limited slip heavy-duty and (Z82) Trailering equipment heavy duty
• SEATS FRONT RECLINING BUCKETS INBOARD ARMRESTS DUAL ADJUSTABLE HEAD RESTRAINTS includes (AG1) Seat adjuster power driver 6-way and storage pockets
• Four Wheel Drive
• Four Wheel Drive
• Tow Hooks
• Tires - Front All-Season
• Tires - Rear All-Season
• Conventional Spare Tire
• Power Steering
• ABS
• Front Disc/Rear Drum Brakes
• Automatic Headlights
• Daytime Running Lights
• Automatic Headlights
• Fog Lamps
• Heated Mirrors
• Power Mirror(s)
• Privacy Glass
• Intermittent Wipers
• Cloth Seats
• Split Bench Seat
• Pass-Through Rear Seat
• Rear Bench Seat
• Front Reading Lamps
• Floor Mats
• Adjustable Steering Wheel
• Leather Steering Wheel
• Immobilizer
• Trip Computer
• Cruise Control
• Power Door Locks
• Power Windows
• Security System
• Keyless Entry
• Power Door Locks
• Rear Defrost
• Multi-Zone A/C
• A/C
• AM/FM Stereo
• CD Player
• Power Outlet
• Auto-Dimming Rearview Mirror
• Passenger Vanity Mirror
• Front Reading Lamps
• ABS
• Front Disc/Rear Drum Brakes
• Driver Air Bag
• Passenger Air Bag
• Passenger Air Bag Sensor
• Daytime Running Lights
• Automatic Headlights

• Brakes
• Brake ABS System: Four-Wheel
• Brake Type: Pwr
• Disc - Front (Yes or ): Yes
• Disc - Rear (Yes or ): Yes
• Front Brake Rotor Diam x Thickness (in): 12.0 x 1.10
• Rear Brake Rotor Diam x Thickness (in): 12.8 x 0.78
• Cargo Area Dimensions
• Cargo Box (Area) Height (in): 19.5
• Cargo Box Length : Floor (in)
• Cargo Box Width : Floor (in)
• Cargo Box Width : Top, Rear (in)
• Cargo Box Width : Wheelhousings (in)
• Cargo Volume (ft³): 59.0
• Tailgate Width (in): 64.8
• Cooling System
• Total Cooling System Capacity (qts): 13.4
• Electrical
• Cold Cranking Amps : 0° F (2nd)
• Cold Cranking Amps : 0° F (Primary)
• Maximum Alternator Capacity (amps): 145
• Exterior Dimensions
• Cab to Axle (in): 41.9
• Front Bumper to Back of Cab (in): 138.5
• Ground Clearance, Front (in): 8.7
• Ground Clearance, Rear (in): 8.6
• Ground to Top of Load Floor (in): 33.7
• Height, Overall (in): 73.9
• Length, Overall w/o rear bumper (in): 230.2
• Overhang, Front (in): 36.9
• Overhang, Rear w/o bumper (in): 47.3
• Wheelbase (in): 143.5
• Width, Max w/o mirrors (in): 78.5
• Frame
• Frame Type: Ladder
• Fuel Tank
• Fuel Tank Capacity, Approx (gal): 26
• Fuel Tank Location: LH
• Interior Dimensions
• Front Head Room (in): 41.0
• Front Hip Room (in): 61.4
• Front Leg Room (in): 41.3
• Front Shoulder Room (in): 65.2
• Passenger Capacity: 5
• Second Head Room (in): 38.4
• Second Hip Room (in): 61.4
• Second Leg Room (in): 33.7
• Second Shoulder Room (in): 66.3
• Mileage
• EPA Fuel Economy Est - City (MPG): 15
• EPA Fuel Economy Est - Hwy (MPG): 19
• Steering
• Steering Type: Pwr
• Turning Diameter - Curb to Curb (ft): 45.8
• Summary
• Body Code: E63
• Body Style: Ext Cab 6.5' Wideside
• Vehicle Name: GMC Sierra 1500
• Suspension
• Axle Capacity - Front (lbs): 3925
• Axle Capacity - Rear (lbs): 3750
• Axle Ratio (:1) - Front: 3.42
• Axle Ratio (:1) - Rear: 3.42
• Axle Type - Front: Independent
• Axle Type - Rear: Semi-Floating
• Shock Absorber Diameter - Front (mm): 36
• Shock Absorber Diameter - Rear (mm): 36
• Spring Capacity - Front (lbs): 3925
• Spring Capacity - Rear (lbs): 3750
• Stabilizer Bar Diameter - Front (in): 1.12
• Suspension Type - Front: Torsion Bar
• Suspension Type - Rear: 2-Stage Multi-Leaf
• Tires
• Front Tire Order Code: QVL
• Front Tire Size: P265/70R17
• Rear Tire Order Code: QVL
• Rear Tire Size: P265/70R17
• Revolutions/Mile : 45 mph - Front
• Revolutions/Mile : 45 mph - Rear
• Revolutions/Mile : 45 mph - Spare
• Spare Tire Order Code: QVL
• Spare Tire Size: P265/70R17
• Trailering
• Dead Weight Hitch - Max Tongue Wt. (lbs): 750
• Dead Weight Hitch - Max Trailer Wt. (lbs): 5000
• Fifth Wheel Hitch - Max Tongue Wt. (lbs): 1725
• Fifth Wheel Hitch - Max Trailer Wt. (lbs): 6900
• Wt Distributing Hitch - Max Tongue Wt. (lbs): 1155
• Wt Distributing Hitch - Max Trailer Wt. (lbs): 7700
• Weight Information
• Curb Weight - Front (lbs): 2999
• Curb Weight - Rear (lbs): 2009
• Gross Axle Wt Rating - Front (lbs): 3925
• Gross Axle Wt Rating - Rear (lbs): 3750
• Gross Combined Wt Rating (lbs): 13000
• Gross Vehicle Weight Rating Cap (lbs): 6400
• Wheels
• Front Wheel Material: Aluminum
• Front Wheel Size (in): 17 x 7.5
• Rear Wheel Material: Aluminum
• Rear Wheel Size (in): 17 x 7.5
• Spare Wheel Material: Steel
• Spare Wheel Size (in): 17 x 7.5
