• 12V pwr outlet
• AM/FM stereo w/CD player-inc: CD changer control, (4) speakers
• Cigar lighter
• Floor tunnel insulation
• Instrument cluster-inc: 120 MPH primary speedometer, tachometer
• Passenger assist handle
• Rear cab storage
• Tilt steering column

• 136-amp alternator
• 600-amp maintenance-free battery
• 9.25" rear axle ring gear diameter
• Front stabilizer bar
• Full-size spare tire w/steel wheel & winch-type carrier
• HD front & rear shock absorbers
• Pwr rack & pinion steering
• Rear wheel drive
• Trailer tow wiring-inc: 4-pin connector

• Driver/passenger multistage airbags w/passenger on/off switch
• Dual note horn
• Shoulder belt height adjusters

5-SPEED AUTOMATIC TRANSMISSION

3.55 axle ratio

MONOTONE PAINT

(STD)

• 5-SPEED AUTOMATIC TRANSMISSION (STD)
• MONOTONE PAINT (STD)
• OVER RAIL BOX BEDLINER
• EXTRA COST PEARL PAINT
• EXTRA COST METALLIC PAINT
• TWO-TONE "LOWER BREAK" PAINT
• 3.55 AXLE RATIO
• MANUFACTURER STATEMENT OF ORIGIN
• SLIDING REAR WINDOW
• Rear Wheel Drive
• Tires - Front All-Season
• Tires - Rear All-Season
• Conventional Spare Tire
• Power Steering
• Intermittent Wipers
• Variable Speed Intermittent Wipers
• Split Bench Seat
• Adjustable Steering Wheel
• A/C
• AM/FM Stereo
• CD Player
• Power Outlet
• Driver Air Bag
• Passenger Air Bag
• Passenger Air Bag On/Off Switch
• Passenger Air Bag Sensor

• Mileage
• EPA Fuel Economy Est - City (MPG): 14
• EPA Fuel Economy Est - Hwy (MPG): 19
• Electrical
• Cold Cranking Amps @ 0° F (Primary): 600
• Maximum Alternator Capacity (amps): 136
• Maximum Alternator Watts: - TBD -
• Cooling System
• Total Cooling System Capacity (qts): - TBD -
• Weight Information
• Gross Axle Wt Rating - Front (lbs): 3700
• Gross Axle Wt Rating - Rear (lbs): 3900
• Curb Weight - Front (lbs): 2751
• Curb Weight - Rear (lbs): 2064
• Gross Vehicle Weight Rating Cap (lbs): 6600
• Gross Combined Wt Rating (lbs): 9000
• Trailering
• Dead Weight Hitch - Max Trailer Wt. (lbs): 4050
• Dead Weight Hitch - Max Tongue Wt. (lbs): 405
• Wt Distributing Hitch - Max Trailer Wt. (lbs): 4050
• Wt Distributing Hitch - Max Tongue Wt. (lbs): 405
• Suspension
• Suspension Type - Front: Independent SLA
• Suspension Type - Rear: Leaf spring
• Spring Capacity - Front (lbs): - TBD -
• Spring Capacity - Rear (lbs): - TBD -
• Axle Type - Rear: Semi-floating
• Axle Capacity - Front (lbs): - TBD -
• Axle Capacity - Rear (lbs): - TBD -
• Axle Ratio (:1) - Front: N/A
• Axle Ratio (:1) - Rear: 3.55
• Axle Ratio (:1) - Rear: 3.21
• Shock Absorber Diameter - Front (mm): - TBD -
• Shock Absorber Diameter - Rear (mm): - TBD -
• Stabilizer Bar Diameter - Front (in): - TBD -
• Brakes
• Brake Type: Pwr
• Brake ABS System: Rear Wheel
• Disc - Front (Yes or ): Yes
• Disc - Rear (Yes or ): Yes
• Front Brake Rotor Diam x Thickness (in): - TBD -
• Rear Brake Rotor Diam x Thickness (in): - TBD -
• Tires
• Front Tire Order Code: TSB
• Rear Tire Order Code: TSB
• Spare Tire Order Code: TSB
• Front Tire Size: P245/70R17
• Rear Tire Size: P245/70R17
• Spare Tire Size: P245/70R17
• Front Tire Capacity (lbs): - TBD -
• Rear Tire Capacity (lbs): - TBD -
• Spare Tire Capacity (lbs): - TBD -
• Revolutions/Mile @ 45 mph - Front: - TBD -
• Revolutions/Mile @ 45 mph - Rear: - TBD -
• Revolutions/Mile @ 45 mph - Spare: - TBD -
• Wheels
• Front Wheel Size (in): 17 x 8.0
• Rear Wheel Size (in): 17 x 8.0
• Spare Wheel Size (in): 17 x 8.0
• Front Wheel Material: Aluminum
• Rear Wheel Material: Aluminum
• Spare Wheel Material: Steel
• Steering
• Steering Type: Pwr rack & pinion
• Steering Ratio (:1), On Center: - TBD -
• Steering Ratio (:1), At Lock: - TBD -
• Turning Diameter - Curb to Curb (ft): 44.6
• Turning Diameter - Wall to Wall (ft): - TBD -
• Frame
• Frame Type: Ladder
• Fuel Tank
• Fuel Tank Capacity, Approx (gal): 35
• Fuel Tank Location: Inboard Frame Rails
• Exterior Dimensions
• Wheelbase (in): 140.5
• Length, Overall w/o rear bumper (in): 229.7
• Width, Max w/o mirrors (in): 79.9
• Height, Overall (in): 74.1
• Overhang, Front (in): 39.4
• Overhang, Rear w/o bumper (in): - TBD -
• Front Bumper to Back of Cab (in): - TBD -
• Cab to Axle (in): - TBD -
• Cab to End of Frame (in): - TBD -
• Ground to Top of Load Floor (in): 33.8
• Ground to Top of Frame (in): - TBD -
• Frame Width, Rear (in): - TBD -
• Ground Clearance, Front (in): 8.3
• Ground Clearance, Rear (in): 8.1
• Cargo Area Dimensions
• Cargo Box Length @ Floor (in): - TBD -
• Cargo Box Width @ Top, Rear (in): - TBD -
• Cargo Box Width @ Floor (in): 66.4
• Cargo Box Width @ Wheelhousings (in): 51.0
• Cargo Box (Area) Height (in): 20.2
• Tailgate Width (in): 63.5
• Cargo Volume (ft³): - TBD -
• Ext'd Cab Cargo Volume (ft³): N/A
• Interior Dimensions
• Passenger Capacity: 3
• Front Head Room (in): 40.9
• Front Leg Room (in): 41.0
• Front Shoulder Room (in): 67.0
• Front Hip Room (in): 65.1
• Summary
• Vehicle Name: Dodge Ram 1500
• Body Style: Reg Cab 8' Bed
• Body Code: 140.5" WB
